The TAD‐M1000TX is an evolution in high‐power amplification, featuring 500 W per channel, perfectly balanced circuitry, twin toroidal transformers, Direct‐FET Class‐D output, and vibration‐controlled design. It delivers robust, transparent, and emotionally stirring performance for demanding audiophiles.
SPECIFICATIONS
| MODEL NO. | TAD-M1000TX |
| POWER OUTPUT | 500 W at 1 kHz, 4 Ω |
| RATED DISTORTION | Less than 0.05 % at 1 kHz, 4 Ω |
| SIGNAL-TO-NOISE RATIO | 112 dB or higher |
| FREQUENCY RESPONSE | 10 Hz to 50 kHz, +0/-3 dB |
| GAIN (BALANCE) | 29.5 dB |
| INPUT TERMINAL (SENSITIVITY / IMPEDANCE) |
1.5 V / 100 kΩ (balanced input) 0.75 V / 50 kΩ (unbalanced input) |
| POWER REQUIREMENTS | AC 120 V, 60 Hz (USA) AC 220 V to 230 V, 50 Hz / 60 Hz (Europe / Asia) |
| POWER CONSUMPTION | 250 W |
| STANDBY POWER CONSUMPTION | 0.5 W |
| DIMENSIONS | Not specified |
